Stardex® 2155 – Angle Board

Premium Tapioca-Maize Blend Adhesive Powder for Angle Board Manufacturing

A carefully engineered blend of tapioca and maize-based modified starches designed specifically for high-speed angle board lines. It delivers the ideal balance of open time, green tack, and final compression strength that forward-thinking manufacturers demand.

Angle board (paper edge protectors) must withstand significant stacking loads, strapping tension, and transit impacts while maintaining dimensional stability. Stardex® 2155-Angle Board addresses the two most critical performance parameters — Open Time and Compression Strength — through precise control of viscosity, water retention, penetration behavior, and film-forming properties.

Applications

Angle Board Manufacturing

Paper Corner Protectors

Edge Protectors for Packaging

Laminated Paper Board Bonding

High-Speed Angle Board Production Lines

Industrial Packaging Components

Compression-Strength Optimized Adhesive Systems

Paper-Based Structural Packaging Products

Heavy-Duty Load Stabilization Packaging

Protective Packaging Reinforcement Solutions

Key Benefits

Optimized Open Time

Engineered for a wide, controllable bonding window that supports high-speed lamination without premature drying or excessive slip. This prevents delamination during compression and enables reliable operation even on faster lines.

Superior Green Tack and Initial Bond Strength

Develops strong ply adhesion immediately after lamination, reducing rejects and allowing boards to hold shape during handling and early curing stages.

Exceptional Compression Strength

Creates a rigid, fiber-anchored network between plies that significantly enhances edge crush, flat crush, and vertical load-bearing capacity — critical for warehouse stacking and transport protection.

Efficient Penetration Control

Balances surface tack with controlled fiber penetration to form strong mechanical anchoring without starving the glue line or creating weak surface-only bonds.

High Film Strength After Drying

Forms a tough, flexible-yet-rigid starch film that boosts overall board rigidity and crush resistance.

Low Consumption & Cost Optimization

Higher solids content and excellent adhesive efficiency typically reduce usage per ton of finished board compared to standard native or single-base starches.

Batch-to-Batch Consistency

Tight viscosity control ensures stable machine runnability, minimal adjustments, and predictable performance.

Fast Drying Under Pressure

Supports rapid curing without compromising bond quality, improving overall line productivity.

Property	Specification	Specification
Raw material Base	Tapioca & Maize Starch Blend	Pure Maize Starch
Powder to Water Ratio	1.1.5 \| 1.1.2	1.1.5 \| 1.1.2
Viscosity, Brookfield Viscometer Spindle #4, 20 RPM	700 Cps \| 1490 cps	820 Cps \| 2000 Cps
Solids	38% \| 41%	35% \| 44%
pH	9 to 11 \| 9 to 11	9 to 11 \| 9 to 11
B6 Cup	40-60 seconds \| 40-60 seconds	40-60 seconds \| 40-60 seconds
Solubility	Cold water \| Cold water	Cold water \| Cold water
Appearance	Light Yellow Powder \| Light Yellow Powder	Light Yellow Powder \| Light Yellow Powder
Appearance	Light Yellow Powder \| Light Yellow Powder	Light Yellow Powder \| Light Yellow Powder
Moisture	3 to 5% \| 3 to 5%	3 to 5% \| 3 to 5%

Packaging Options

25 kg multi-layer paper bags (standard, palletized)

Bulk big bags (FIBC) for high-volume users — available with custom liner options for moisture protection
